6790-93-80CP

Shower Mixer Body


The design of Arch Series combines well-executed lines and smooth curves to come into the sharply contrastive but perfect visional impression to reveal beauty of mordent fashion and historical culture.


Color: Polished Chrome

  • CP

Share

Download

6790-93-80CP Overview

6790-93-80CP Specification

6790-93-80CP Installation


1.Universal mold design which uses common parts and increase more convenient for maintained.
2.Ceramic valve with CERAMTEC ceramic disc / (Germany)
3.Handle can be moved up to 22° to adjust water flow from closed position; hot and cold water controlled by swinging handle for 45° both right and left sides.
4.The available distance between two centers of wall water-outlet is 122mm to 178mm.
5.With R 1/2 to water supply wall outlet.
6.Casting material meets ISO CuZn40Pb Standard.
7.Handle material meets JIS 3771 Standard.
8.Brass with Chrome plated, meet ASTM-SC2 standard.
