6777-X4-81MA
Single-Handle Built-In Bath Mixer
Seed is the fountainhead of all creation, but not all seeds are lucky to sprout and then grow up, so each budding seed is the symbol of hope and happiness. Moreover, spout of “Lucky 7”is like growing stalk to present various styles as creative ideas of designers.
Succinct pillared shape design simplified lines of spout and handle for not only presenting complete figure to be brief and elegant, but also decreasing time and cost of production.
Handle has been designed to operate easily in wet or slippery conditions.
Color: Matt black
Share
Download
1.Material of forging body and handle meets JIS 3771 standard.
2.Material: Brass
3.Material of shower tube meets JIS C2700 standard.
4.Main Body Material: Brass
5.Material of body meets JIS 3771 standard.
6.Ceramic valve with CERAMTEC ceramic disc / (Germany)
7.Handle valve turning range from closed position: 90°
8.Handle can be moved up to 22° to adjust water flow from closed position; hot and cold water controlled by swinging handle for 45° both right and left sides.
9.Past 500,000 times lifespan test.
10.1.5 meter elastic shower hose can be extended.
11.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 10 Kg/cm2 water pressure and 120℃ heat.
12.Shower hose with TPE flexible tube, can stand 10Kg/cm2 water pressure and 70℃ heat.
13.The mixing valve could be installed in the cemented and wood wall.
14.Thread: G 1/2
15.The faucet can stand the presure from 0.5 to
Authorization Code
6777-X4-81MA SketchUp
