Shower Mixer W/Hand Shower & Hose & Wall Bracket

Designed main body style as square shape, the aesthetics of symmetry exudes a stylish and charming atmosphere. With R angle processed, it soften the right angle of hard steel, and bring more soft and elegant atmosphere to a bathroom space.

Color: Polished Chrome

  • Shower Mixer W/Hand Shower & Hose & Wall Bracket


7909-93-81CP Overview

7909-93-81CP Specification

7909-93-81CP Installation

1.The smooth line of handle is the feature.
2.The spray head of hand shower can be removed easily by easy-tool provided for cleaning.
3.Ceramic valve with KOREA ceramic disc / (Korea)
4.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water controlled by swinging handle for 45° both right and left sides.
5.The available distance between two centers of wall water-outlet is 122mm to 178mm.
6.Elastic shower hose can be extended from 1.5 meter to 2 meter and stand 15Kg/cm2 water pressure.
7.With R 1/2 to water supply wall outlet.
8.Brass with Chrome plated meets ASTM-SC2 standard.
9.Casting body material meets ISO CuZn40Pb Standard.
10.Forging handle material meets JIS 3771 Standard.
