6790-91-81CP

Two-Handle Basin Faucet W/Lift Rod


The design of Arch Series combines well-executed lines and smooth curves to come into the sharply contrastive but perfect visional impression to reveal beauty of mordent fashion and historical culture.


Color: Polished Chrome

  • Two-Handle Basin Faucet W/Lift Rod

Share

Download

6790-91-81CP Overview

6790-91-81CP Specification

6790-91-81CP Installation


1.Ceramic cartridge with brass shell & Japan (MARUWA) ceramic disc.
2.Handle valve turning range from closed position:  90°
3.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can stand15Kg/cm2 water pressure and 120℃ heat.
4.Stainless steel braided hose with M10 x 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supply system).
5.Aerator with removable flow restrictor (2.2 GPM max.), end-user can take off it for larger water flow if necessary.
6.Material is Brass with Chrome plated and meets ASTM-SC2 standard; 5 years guarantee.
7.Sand-casting material meets ISO CuZn40Pb Standard
8.Handle material meets JIS 3771 Standard


Authorization Code

6790-91-81CP SketchUp
