6780-90-80CP

Basin Faucet


Utilizing the simplify concept of Tai Chi motion, creating extraordinary look on the Tai Chi Series faucets. Featuring the Tai Chi notion of "soft against hard" through its soft cut of the faucet body and flow of water. Adding into faucet, the "Yin and Yang" aspect of Tai Chi, creating two types of faucets, the femininity and masculinity.


Color: Polished Chrome

  • CP

Share

Download

6780-90-80CP Overview

6780-90-80CP Specification

6780-90-80CP Installation


1.Ceramic valve with CERAMTEC ceramic disc / (Germany)
2.Handle can be moved up to 22° to adjust water flow from closed position; hot and cold water controlled by swinging handle for 45° both right and left sides.
3.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can stand15Kg/cm2 water pressure and 120℃ heat.
4.Stainless steel braided hose with M10 x 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supply system).
5.Brass with Chrome plated meets ASTM-SC2 standard; 5 years guarantee.
6.Casting material meets ISO CuZn40Pb Standard
7.Handle material meets JIS 3771 Standard


Authorization Code

6780-90-80CP SketchUp

6780-90-80CP CAD
