6771-91-80CP

Basin Faucet (Brass)


Inspired by the main design conception of “Less is More,” Still One used brief lines and a simple model to integrate the practicality and elegance with the concise design style. It also fits for the general kitchen arrangement- small and saving space.The product is made of lead-free brass or stainless steel, which both meet NSF Standard.


Color: Polished Chrome

  • CP

Share

Download

6771-91-80CP Overview

6771-91-80CP Specification

6771-91-80CP Installation


1.Swiveling spout has passed up to 50,000 turns test. It can be adjusted by user.
2.Ceramic valve with CERAMTEC ceramic disc / (Germany)
3.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water control by swinging handle 45°.
4.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 15Kg/cm2 water pressure and 120℃ heat.
5.Stainless steel braided hose with M10 × 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supplier system).
6.Aerator with removable flow restrictor (2.2 GPM max.), end-user can take off it for larger water flow if necessary.
7.Material is Brass with Chrome plated and meets ASTM-SC2 standard.
8.Spout material meets JIS C2700 Standard.
9.Faucet body material meets JIS 3771 Standard.


Authorization Code

6771-91-80CP SketchUp

6771-91-80CP CAD
