7909-93-80CP

Shower Mixer Body


Designed main body style as square shape, the aesthetics of symmetry exudes a stylish and charming atmosphere. With R angle processed, it soften the right angle of hard steel, and bring more soft and elegant atmosphere to a bathroom space.


Color: Polished Chrome

  • CP

Share

Download

7909-93-80CP Overview

7909-93-80CP Specification

7909-93-80CP Installation


1.The smooth line of handle is the feature.
2.Ceramic valve with KOREA ceramic disc / (Korea)
3.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water controlled by swinging handle for 45° both right and left sides.
4.The available distance between two centers of wall water-outlet is 122mm to 178mm.
5.With R 1/2 to water supply wall outlet.
6.Brass with Chrome plated meets ASTM-SC2 standard.
7.Casting body material meets ISO CuZn40Pb Standard.
8.Forging handle material meets JIS 3771 Standard.
