6926-TF-80CP

Thermostatic Rainshower System


Water is necessary of life, and container of water is the important chapter of human culture, such as teapot of eastern culture, pot for garden, and milk pot play major roles for western culture. Chapter Faucets represent concept and imagination of water container of western and eastern culture to combine with modern lines to display simple beauty and present brand-new chapter of water and containers.



Color: Polished Chrome

  • CP

Share

Download

6926-TF-80CP Overview

6926-TF-80CP Specification

6926-TF-80CP Installation

6926-TF-80CP Exploded View


1.Faucet body with casting brass meets ISO CuZn40Pb standard.
2.Material of handles meet JIS 3771 standard.
3.Brass hand shower meets JIS 3604 standard.
4.Chrome plated finish meets the standard of ASTM-SC2.
5.With G 1/2 thread to water supply wall outlet.
6.Safety stop at 40°C. Temperature pre-adjustable by the mixer valve.
7.The available distance between two centers of wall water-outlet is 116mm to 174mm.
8.1.5 meter elastic shower hose can be extended. Shower hose with TPE flexible tube, can bear 10Kg/cm2 water pressure and 70℃ heat.
9.The valve is capable of connecting with hand shower and overhead shower. Horizontal swiveling and vertical moving holder of hand shower provides more convenience.
10.The inlet of both sides on the valve are assembled with the check valves to avoid the backflow of cold and hot water.
11.Coordinates with other products in Chapter collection.


Authorization Code

6926-TF-80CP SketchUp

6926-TF-80CP CAD
