6767-90-80S1
Basin Faucet
This series is a typical cylindrical body design, which shows a balanced and symmetrical beauty. The special shape of the flame handle, as a symbol of hope. Overall mix to create a noble, harmonious visual experience.
Color: Brushed
Share
Download
1.The brushed surface is easy to cleaning for the faucet.
2.Ceramic valve with CERAMTEC ceramic disc / (Germany)
3.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water control by swinging handle 45° both right and left.
4.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 15Kg/cm2 water pressure and 120℃ heat.
5.Stainless steel braided hose with M10 × 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supplier system).
6.Aerator with removable flow restrictor (2.2 GPM max.), end-user can take off it for larger water flow if necessary.
Authorization Code
6767-90-80S1 SketchUp
