6875-93-81CP

Shower Mixer W/Hand Shower & Hose & Wall Bracket


YES Series Mixers have been designed with the brief lines and geometric cylinder to simplify the outer shape and present the absolute image for Bath Mixers. It has been integrated the concept of ergonomics with 120 degrees design for the Handle, Body, and Spout to achieve simplest design with least material. Raising Handles provide convenient operation for users. YES Mixers have broken the heavy image of bath mixer, and designed with less material to create slim shape to increase the fitness in the bathroom interior arrangements.



Color: Polished Chrome

  • CP

Share

Download

6875-93-81CP Overview

6875-93-81CP Specification

6875-93-81CP Installation


1.Anticorrosive surface treatment of copper products, easy to clean and maintain
2.The specifications of the wall outlet pipe teeth are applicable: G 1/2, R 1/2, 1/2 PT, 1/2 NPSM, 1/2 NPT
3.The left and right water inlets are provided with check valves to prevent cold and hot water from flowing back
4.Body connector specification is G 1/2
5.Applicable water pressure 1 ~ 4 (kg / cm ^ 2)
6.1.5m flexible telescopic hose can be stretched to 2m.
7.The shower hose has a built-in TPE flexible hose, which can bear water pressure 10kg / cm ^ 2 and temperature 70 ℃.
